HP Device Manager 4.6 - Database Schema Guide

Table Of Contents

dm_group_values

This is the grouping values table, which stores the grouping values set from the HPDM Console. When the HPDM Console

displays grouping values, the values in this table have a higher priority than the values in the dm_devices table.

1. Table columns

Column name Type name Column size Nullable Primary key Description

device_id nvarchar 50 NO √

p1 nvarchar 50 YES

p2 nvarchar 50 YES

p3 nvarchar 50 YES

p4 nvarchar 50 YES

p5 nvarchar 50 YES

p6 nvarchar 50 YES

grouping int 10 YES

2. Relevant UI
