HP XP7 Replication Manager Application Agent CLI Reference Guide (TK981-96014, May 2014)

When you specify the -cascade option, a backup catalog is automatically transferred to a backup
server defined in the cascade configuration information definition file. The backup catalog is transferred
to a backup server on both the local site and the remote site.
-auto_mount mount-point-directory-name
Specify this option to automatically mount a secondary volume on a backup server after backing up
a volume. This option must be specified concurrently with other options by using the combinations in
either 1 or 2 below.
1. The -s and -auto_import options
2. The -cascade and -auto_import options
Specify mount-point-directory-name by using a character string of up to 64 bytes.
If you omit the mount-point-directory-name parameter, a mount destination for a secondary
volume is automatically determined. This destination is determined in the same way as when using
the drmmount command without specifying a mount point.
Execute the drmumount command to unmount the mounted secondary volume. In the argument of
the drmumount command, specify the backup ID.
-svol_check
Specify this option to check the status of a secondary volume on a backup server. This option must
be specified concurrently with the -s option. Checking the status of a secondary volume prevents
backup or restoration failures. The items, volumes, and conditions to be checked are described in the
following table.
Table 46 Status check of a secondary volume
Check conditions
Volume to be
checked
Check items
Checked if a primary volume is defined in pairs with secondary
volumes of multiple generations and if at least one of the
following conditions is satisfied:
• A primary volume is a cluster resource.
• A backup using VSS is performed.
All secondary
volumes defined for
a backup-target
primary volume
A secondary volume
is hidden from a
backup server
Always checked.
The secondary
volume to be the next
backup destination
A secondary volume
is not mounted on a
backup server
This option must not be specified concurrently with the -cascade option.
-cascade
Specify this option to perform a backup on both the local site and remote site concurrently when
configuring a cascade.
After the backup finishes, a backup catalog is registered on the local site and remote site respectively.
The same copy group and MU# of the local site is also used on the remote server.
You cannot specify this option concurrently with the following options:
• -s
• -pf
• -svol_check
Application Agent CLI Reference Guide 189
