Setting up logs and alerts
93
6 Setting up logs and alerts
This chapter describes the settings required to use Device Manager to monitor the status of the
system and monitor for errors.
• Settings for integrated logs (section 6-1 )
• Settings required for generating audit logs (section 6-2 )
• Settings required for centrally managing storage subsystem alerts (section 6-3 )
• Settings required for email notification (section 6-4 )
6-1 Settings for integrated logs
The XP Command View AE Suite Common Component provides a common library used to acquire
log data for XP Command View AE Suite products, which use common log files. Device Manager
uses this library to output log data to log files. The following section gives details about log files.
6-1-1 Setting the number of Common Component trace log
files
You can set a maximum of 16 trace log files. However, a larger number of trace log files can make it
more difficult to find specific information.
CAUTION: Changing the common trace log settings affects other program products that use the
common trace logs.
6-1-1-1 In Windows
The Windows HNTRLib2 utility is located as follows:
program-files-folder\Hitachi\HNTRLib2\bin\hntr2util.exe
To specify the number of trace log files:
1. Log in to the system as a user with Administrator privileges.
2. Execute hntr2util.exe.
The Hitachi Network Objectplaza Trace Utility 2 window is displayed.
Figure 6-1 Hitachi network objectplaza trace utility 2 window
