Settings required for linking with related products
88
6. If necessary, use the GUI of HP SIM to add the users who are to use XP Command View AE
Suite products.
If a user is to use XP Command View AE Suite products, the HP SIM user ID will be domain-
name\HP-SIM-user-name. The available characters used for specifying domain-name\HP-
SIM-user-name (except \) and the number of those characters must follow both the rules for
specifying a user ID for XP Command View AE Suite products and the rules for specifying a
user ID for the HP SIM OS. For details on the rules for XP Command View AE Suite products,
see the HP StorageWorks XP Command View Advanced Edition software Device Manager
Help.
If there is no user ID that follows these rules, add a user. For details on how to add a user, see
the HP Systems Insight Manager Installation and Configuration Guide.
7. Using the GUI of HP SIM, add permission for users who are to use XP Command View AE
Suite products.
Add tool No. 1 (essential) and any of the tools from No. 2 to No. 4, shown in
Table 5-1, to the
toolbox. Permissions used when users operate XP Command View AE Suite products are
determined by the tools to be added. The correspondence between tool names and
permissions of Device Manager is shown in the table below. For details on permissions in XP
Command View AE Suite products other than Device Manager, see
Table 5-1.
Table 5-1 Tools for Device Manager
No. Category Tool name Description
1 Command View XP Command View AE This tool is required
for starting Device
Manager from HP
SIM. Add this
permission for all
users who are to
use XP Command
View AE Suite
products.
2 XP Command View AE as Administrator Add this tool to
users who are to be
given the Admin
permission of
Device Manager.
3 XP Command View AE as Operator Add this tool to
users who are to be
given the Modify
permission of
Device Manager.
4 XP Command View AE as User Add this tool to
users who are to be
given the View
permission of
Device Manager.
If the administrator adds multiple tools from No. 2 to No. 4, the level of the XP Command View
AE Suite permission that was granted to the user determines which tools can be used by the
user. The following list shows the tools in order of the permissions required (highest level first):
1. XP Command View AE as Administrator
2. XP Command View AE as Operator
3. XP Command View AE as User
For details on how to add a tool, see the HP Systems Insight Manager Installation and
Configuration Guide.
8. For all users who are to use XP Command View AE Suite products, use Authorizations in the
GUI of HP SIM to authenticate the toolbox to which you added tools in step 7 and the
management server onto which Device Manager was installed.
