Settings for various network configurations
62
Table 2-12 Port numbers that must be registered as exceptions to a firewall between the
management server and a mail server
Port number Originator Destination Remarks
25/tcp
*
Management server
(Device Manager server)
Mail server
(for the email notification
function of the Device
Manager server)
This setting is required when the
email notification function of the
Device Manager server is used.
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and an external authentication server.
Table 2-13 Port numbers that must be registered as exceptions to a firewall between the
management server and an external authentication server
Port number Originator Destination Remarks
88/tcp
*
Management server Kerberos server -
88/udp
*
Management server Kerberos server -
359/tcp
*
Management server LDAP directory server -
1812/udp
*
Management server RADIUS server -
*/udp
*
RADIUS server
Kerberos server
Management server -
Legend
--: Not applicable
*
This port number is generally used. However, a different port number might be used for an external
authentication server.
2-1-4 Registering firewall exceptions in a Linux environment
In Linux environments, you must register firewall exceptions manually using the text mode setup
utility.
For details on ports to be registered, see section
2-1-3 .
2-1-4-1 In Red Hat Enterprise Linux
To register a firewall exception by using the text mode setup utility:
1. In a terminal window, execute the setup command.
The Choose a Tool window of the text mode setup utility is displayed.
2. Select Firewall configuration, use the tab key to move to Run Tool, and then press Enter.
The Firewall Configuration window is displayed.
3. Set Security Level to Enabled by pressing the space key to select Enabled, use the tab key to
move to Customize, and then press Enter.
The Firewall Configuration - Customize window is displayed.
4. In Other ports specify the port to be registered as an exception, use the tab key to move to
OK, and then press Enter.
Example: Other ports 162:udp 2001:tcp 23015:tcp
NOTE: If a port is already specified, use a space to separate it from the newly added entry.
