Settings for various network configurations
59
Table 2-5 Port numbers that must be registered as exceptions to a firewall between the
management server and storage subsystems
Port number Originator Destination Remarks
51099/tcp
Management server
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
51100/tcp
Management server
• XP24000/XP20000
This setting is required when
you perform an upgrade
installation to a Device
Manager server version 6.0.0-
00 or later.
Legend
--: Not applicable
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management client and storage subsystems.
Table 2-6 Port numbers that must be registered as exceptions to a firewall between the
management client and storage subsystems
Port number Originator Destination Remarks
80/tcp
Management client
(web client)
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
443/tcp
Management client
(web client)
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
This setting is required when
using SSL to start Physical
View.
1099/tcp
Management client
(web client)
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
51099/tcp
Management client
(web client)
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
