Overview
35
By using Device Manager, you can perform the following operations for SMI-S Enabled subsystems:
• Add or delete a storage subsystem
• Refresh a storage subsystem
• View configuration information for a storage subsystem
• Change the properties of a storage subsystem
• Start the storage subsystem management tools
The following table lists SMI-S Enabled subsystems usable as external subsystems.
Table 1-19 SMI-S Enabled subsystems usable as external subsystems
Vendor Model Prerequisite SMI-S
providers
HP
• EVA 3000
• EVA 4100
• EVA 4400
• EVA 5000
• EVA 6100
• EVA 6400
1
• EVA 8100
• EVA 8400
1
• HP Command View EVA
8.0.2 or later
SMI-S: version 1.2 or later
EMC
• CLARiiON CX200
2
• CLARiiON CX300
2
• CLARiiON CX400
2
• CLARiiON CX500
2
• CLARiiON CX600
2
• CLARiiON CX700
2
• CLARiiON CX3 series
2
• EMC SMI-S Provider 3.3 or
later (prerequisite program:
EMC Solutions Enabler 6.5
or later)
SMI-S: version 1.2 or later
1
To use this model as an external subsystem in XP24000/XP20000, the DKC microcode of
XP24000/XP20000 must be 60-03-10-xx/xx or later.
2
IPv6 cannot be used for communication between the Device Manager server and an SMI-S
provider.
CAUTION:
•
To add SMI-S Enabled subsystems into the Device Manager server, add them separately for each SMI-S
provider from the Add Subsystem dialog box of web client or by using the AddStorageArray command.
If one SMI-S provider manages multiple SMI-S Enabled subsystems, all of those SMI-S Enabled
subsystems supported by Device Manager will be added to the Device Manager server at the same time.
• If multiple SMI-S providers manage one SMI-S Enabled subsystem and that subsystem has already been
added to Device Manager, the subsystem will not be added (or refreshed) when another SMI-S provider
that manages the subsystem is registered.
• If the number of SMI-S Enabled subsystems managed by an SMI-S provider increases or decreases, you
need to re-register the same SMI-S provider into the Device Manager server from the Add Subsystem
dialog box of web client or by using the AddStorageArray command (but you do not need to delete it).
• If you change the SMI-S provider that manages an SMI-S Enabled subsystem to another SMI-S provider,
or if you modify the information about the SMI-S provider machine (such as IP address, port number, or
protocol), you need to use Device Manager to change the properties for the SMI-S Enabled subsystem.
