Overview
33
NOTE: If you use the Device Manager to directly manage storage logical partitions, you need a
separate Device Manager server for each partition. If you use the Device Manager to link and
launch XP Remote Web Console, you can use a single server to manage a partitioned disk array.
• If you use XP Continuous Access Software or XP Business Copy Software, see section 1-7 for
the requirements.
• For more information on installing and configuring other software, see XP Remote Web
Console User's Guide.
NOTE: Do not use DHCP if you use Device Manager to manage the storage subsystem.
1-4-3 System requirements for XP1024/XP128
The following table describes the prerequisite firmware versions and software products.
Table 1-17 Prerequisite firmware versions and software products for XP1024/XP128
Prerequisite firmware versions Prerequisite software products
• SVP microcode : 21-14-26-00/00 or later
• Controller microcode to perform in-context
launching of the XP Remote Web Console:
21-04-04-xx/xx or later
• Controller microcode to launch NAS Manager:
21-04-00-xx/xx or later
• Controller microcode to use Open LDEV
Guard function:
21-07-00-xx/xx
• Java API
• HP SNMP API
• XP LUN Manager
• XP Remote Web Console
To use functions for creating a LUSE or LDEV
(CVS):
• XP Virtual LVI/LUN (VLL) and Volume
Shredder
To use the copy pair functionality:
• HP StorageWorks XP Business Copy
Software
• HP StorageWorks XP Continuous Access
Synchronous Software
• XP Continuous Access Asynchronous
Software
To link with NAS Manager:
• NAS/Management
• If you use XP Continuous Access Software or XP Business Copy Software, see section 1-7 for
the requirements.
• For more information on installing and configuring other software, see XP Remote Web
Console User Guide for the XP1024/XP128.
NOTE: Do not use DHCP if you use Device Manager to manage the storage subsystem.
