Overview
30
1-4-1 System requirements for XP24000/XP20000
The following table lists the prerequisite firmware versions and software products.
Table 1-15 Prerequisite firmware versions and software products for XP24000/XP20000
Prerequisite firmware versions Prerequisite software products
• Controller microcode:
60-01-24-xx/xx or later
• Controller microcode to use an XP
Continuous Access Journal function or a
Hitachi Universal Replicator for Mainframe
Software function:
60-03-28-xx/xx or later
• Controller microcode to use a LUSE:
60-04-10-xx/xx or later
• Controller microcode to use the function that
allows LU creation and LU formatting to be
performed separately:
60-01-24-xx/xx or later
• Controller microcode to use when a copy pair
of Hitachi ShadowImage for Mainframe
Software or of Hitachi TrueCopy for
Mainframe Software exists on a managed
XP24000/XP20000:
60-01-62-xx/xx or later
• Controller microcode to use the setup function
of the Thin Provisioning functionality:
60-02-xx-xx/xx or later
• Controller microcode to perform a quick
format:
60-02-2x-xx/xx or later
• Controller microcode to use the performance
information acquisition feature:
60-01-42-xx/xx or later
• Controller microcode to use the function that
links Thin Provisioning and XP Continuous
Access Software, and the function that links
Thin Provisioning and XP Continuous Access
Journal:
60-02-4x-xx/xx or later
• Java API
• XP SNMP Agent
• XP LUN Manager
• XP Remote Web Console
To use functions for creating a LUSE or LDEV
(CVS):
• XP Virtual LVI/LUN (VLL) and Volume
Shredder
To use the copy pair functionality:
• XP Business Copy Software
• Hitachi ShadowImage for Mainframe
Software
*
• XP Continuous Access Software
• Hitachi TrueCopy for Mainframe Software
*
• XP Continuous Access Asynchronous
Software
• Hitachi TrueCopy Asynchronous for
Mainframe Software
*
• XP Continuous Access Journal
• Hitachi Universal Replicator for Mainframe
Software
*
• HP StorageWorks XP Snapshot
*
To use XP External Storage Software:
• XP External Storage Software
To use storage logical partitioning (SLPR) or
cache logical partitioning (CLPR):
• XP Disk/Cache Partition
To use 3DC functionality:
• Cont Access Journal / UR 3DC & 4x4
To use the Thin Provisioning functionality:
• Thin Provisioning
