Overview
21
Table 1-5 Virtual memory requirements for each product (Windows)
Product name Virtual memory requirement (MB)
Device Manager
1
1,024
XP Provisioning Manager (Included in Device Manager)
XP Tiered Storage Manager 600
XP Replication Manager
2
100
NOTE: If you plan to install Device Manager, XP Tiered Storage Manager, and XP Replication Manager, and
if 1,000 MB of virtual memory is already used by the OS and other programs, you must secure more than
3,224 MB of virtual memory.
1,024 (for Device Manager) + 600 (for XP Tiered Storage Manager) + 100 (for XP Replication Manager) + 500
(for Common Component) + 1,000 (already used virtual memory) = 3,224
1
If the Device Manager agent is installed on the management server, you need to allocate additional virtual
memory for it. For details on virtual memory requirements and allocating virtual memory, see the description
of the server.agent.maxMemorySize property in the HP StorageWorks XP Command View Advanced
Edition software Device Manager agent administrator guide.
2
If XP Replication Manager Application Agent is installed on the management server, you need to allocate
additional virtual memory for it. For details on virtual memory requirements, see the HP StorageWorks XP
Replication Manager software installation and configuration guide.
When you install the Device Manager server, folders require the disk space in the table below.
Note that the program-files-folder\CVXPAE portion can be changed. Read it as the folder
specified during installation.
Table 1-6 Installation folders and required disk space (in Windows)
Item Default installation folder Required disk
space
Installation folder for the Device
Manager server
program-files-
folder\CVXPAE\DeviceManager
1.6 GB
Installation folder for the XP
Provisioning Manager server
program-files-
folder\CVXPAE\ProvisioningManager
Installation folder for Common
Component
program-files-folder\CVXPAE\Base
1
Storage folder of the database for
the Device Manager server
program-files-
folder\CVXPAE\database\DeviceManager
0.6 GB
Storage folder of the database for
Common Component
2
program-files-folder\CVXPAE\database
1.2 GB
program-files-
folder\CVXPAE\database\Base
Installation folder for the common
library
2
program-files-folder\Hitachi\HNTRLib2
1.0 MB
common-program-files-folder\Hitachi
