Appendix A Specifying properties
203
A-9-2 customizedsnmptrap.customizelist
This property allows you to specify how to customize the SNMP trap log output. For details, see
section
6-3-2 .
CAUTION: If you do not specify this property, the SNMP trap data will not be output to the log
even if you specify true for the customizedsnmptrap.customizedSNMPTrapEnable
property.
Default: None
A-10 Device Manager mainframe host agent
properties
Properties of the mainframe host agent are contained in the host.properties file.
• In Windows:
installation-folder-for-the-Device-Manager-
server\Server\config\host.properties
• In Linux:
installation-directory-for-the-Device-Manager-
server/Server/config/host.properties
This properties file contains settings for communication between the Device Manager server and
mainframe hosts.
A-10-1 host.mf.agent.connection.timeout
This property specifies the timeout (in seconds) for communication processing between the Device
Manager server and a Mainframe host agent. Valid values are 0 and from 30 to 3600 (seconds). If
you specify 0, no timeout applies. You should only modify this property if you are an expert System
Administrator seeking to fine-tune performance of the Mainframe host agent.
Default: 300
A-11 Device Manager report function properties
The DvMReport.properties file contains properties of the mainframe host agent.
• In Windows:
installation-folder-for-the-Device-Manager-
server\Server\config\DvMReport.properties
• In Linux:
installation-directory-for-the-Device-Manager-
server/Server/config/DvMReport.properties
A-11-1 DetailedArrayReport.outputPath
This property specifies the storage location of the CSV file that can be generated from the Detailed
Array Reports window in web client.
NOTE: The value specified for the storage location of the CSV file is enabled when the Detailed
Array Reports - Reports subwindow is first displayed on web client after the Device Manager
server service is restarted.
