Overview
20
Table 1-4 Computer requirements (Windows)
Item Requirements
Physical memory Minimum:
512 MB
Recommended:
At least 1 GB
1
Disk space Minimum:
4 GB
Recommended:
At least 5 GB
Monitor XGA (1024 x 768 resolution) or higher.
LAN card 10/100 Ethernet LAN card
If the computer and the LAN cable are compatible with Gigabit
Ethernet, you can use a Gigabit-class card.
CD drive None
Prerequisite program
J2SE Java Runtime Environment 5.0.xx (xx: 03 or later)
2
Microsoft Windows Installer 3.1
2
Supported cluster software In Windows Server 2003 or Windows Server 2003 R2:
Microsoft Cluster Service
In Windows Server 2008
Microsoft Failover Cluster
NOTE: If adequate virtual memory is not allocated on the management server, the XP Command View AE
Suite products and any other installed programs might become unstable or might not start. To ensure stable
operation of the management server, in addition to the virtual memory required for the OS and other
programs, the management server also requires the amount of virtual memory required for both the products
shown in
Table 1-5 and Common Component.
In addition to the virtual memory required for all the products installed on a management server, be sure to
secure enough virtual memory (500MB) for Common Component.
Table 1-5 shows the virtual memory requirements for each product in version 6.4.
1
If the Device Manager server is used simultaneously with other software products, the physical memory
requirements of all of the software products must be taken into account.
2
This program is automatically installed when you install the Device Manager server.
