Troubleshooting
175
Table 10-17 Details of requests and parameters output as XP Provisioning Manager server audit
log data
Request Description Output parameter
GetUGrpByName
Acquires the resource group that
has the specified name.
Resource group name
GetUGrpForVol
Acquires an array of resource
groups to which the specified
volume belongs.
Array of the resource identifiers of
the volume
2
GetUGrps
Acquires an array that indicates
the parent-child relationship of the
resource groups to which the
logon user belongs and the
resource groups immediately
below it.
--
GetUnAllocVolInfos
Acquires a list of volumes to be
displayed in the list of unallocated
LDEVs, and additional information
that indicates the nonconforming
status of the storage subsystem.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan
1
GetUnAllocVols
Acquires a list of volumes to be
displayed in the list of unallocated
LDEVs.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan
1
GetVer
Acquires the version information. --
GetVolForAddDevF
Acquires a list of volumes for
creating a device file.
• Resource identifier of the
target host to which the
volumes being acquired are to
be allocated
2
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
GetVolForAddFSys
Acquires a list of volumes for
creating a file system.
• Resource identifier of the
target host to which the
volumes being acquired are to
be allocated
2
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
GetVolForExpFSys
Acquires a list of volumes for
expanding a file system.
• Resource identifier of the file
system to be expanded
2
• Resource identifier of the
target host to which the
volumes being acquired are to
be allocated
2
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
