Troubleshooting
172
10-4-3 Requests and parameters output as XP Provisioning
Manager audit log data
The following table lists and describes the requests and parameters output as XP Provisioning
Manager audit log data.
Table 10-17
Details of requests and parameters output as XP Provisioning Manager server audit
log data
Request Description Output parameter
AddLicense
Adds a license by using a single
license key.
Fixed to *****
Adds a license by using a license
key file.
Size of the license key file
CreateAllocPl
Creates a new allocation plan. Information about the allocation
plan
1
DelAllocPl
Deletes an allocation plan. Resource identifier of the
allocation plan that is to be
deleted
2
GetAllocPl
Acquires the allocation plan that
has the specified resource
identifier.
Resource identifier of the
allocation plan
2
GetAllocPlByName
Acquires the allocation plan that
has the specified name.
Allocation plan name
GetAllocPls
Acquires all allocation plans that
can be referenced by the logon
user.
--
GetAllocVolInfos
Acquires a list of volumes to be
displayed in the list of allocated
LDEVs, and additional information
that indicates the nonconforming
status of the storage subsystem.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan (if specified)
1
GetAllocVols
Acquires a list of volumes to be
displayed in the list of allocated
LDEVs.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan (if specified)
1
GetConPortInfoByDevF
Acquires the port connection
information that has been set
between the specified device file
and the volume.
• Resource identifier of the
volume
2
• Resource identifier of the
device file
2
GetConPortInfoByHost
Acquires the port connection
information that has been set
between the specified host and
the volume
• Resource identifier of the
volume
2
• Resource identifier of the host
2
GetDevF
Acquires the device file that has
the specified resource identifier.
Resource identifier of the device
file
2
GetDevFByName
Acquires the device file that has
the specified name.
• Resource identifier of the host
2
• Device file name
GetDevFHost
Acquires the device file of the
specified host.
Resource identifier of the host
2
GetDevFsSumByHost
Acquires the device file of the
specified host.
Resource identifier of the host
2
