Troubleshooting
166
Table 10-14 Sequence in which attributes values are output for each element in a detail
message
Output
character string
Full name and content Sequence in which Attribute values are
output
1
name, size, whether the logical volume can be
deleted, whether the logical volume can be
expanded, logical volume type
LVol
LogicalVolume
(Logical volume
information)
name, size, deletable, expandable, type
<PVOL serial number - PVOL LDEV number
4
-
SVOL serial number - SVOL LDEV number
4
>, P-
VOL storage subsystem type
2
, serial number of the
storage subsystem to which P-VOL belongs, P-VOL
device number
4
, port number in the HORCM
configuration file that manages P-VOL paths, S-VOL
storage subsystem type
2
, serial number of the
storage subsystem to which S-VOL belongs, S-VOL
device number
4
, port number in the HORCM
configuration file that manages S-VOL paths, pool
ID to which S-VOL belongs, copy type
5
, P-VOL MU
number, P-VOL fence level
MFRepI
MFReplicationInfo
(Information about
replication of mainframe
volumes)
<pvolSerialNumber - pvolDevNum
4
-
svolSerialNumber - svolDevNum
4
>, pvolArrayType
2
,
pvolSerialNumber, pvolDevNum
4
, pvolPortID,
svolArrayType
2
, svolSerialNumber,
svolDevNum
4
,svolPortID, svolPoolID,
replicationFunction
5
, muNumber, fenceLevel
MFVolI
MFVolumeInfo
(Access information
between the main frame
host and LDEV)
--
Msg
Message
(Asynchronous message)
--
Wait time (seconds)
Msgs
Messages
(Groups the Message
elements)
timeToWait
Object ID, label to give to the object
ObjLabel
ObjectLabel
(Sets the object label of the
Device Manager server)
targetID, label
<target element name - target element identifier>,
name
CAUTION: <target element name> and <target
element identifier> indicate the element name and
element identifier other than those specified for the
ObjectName attribute. For information on the
component corresponding to the element identifier,
see the attribute value output sequence for <target
element name>.
ObjName
ObjectName
(Sets the object name of
the Device Manager server)
<target element name - target element identifier>,
name
PairedJrnlPool
PairedJournalPool
(The journal pool paired
with the journal pool of XP
Continuous Access
Journal)
--
PairedPortCont
roller
PairedPortController
(CHIP paired on the NAS
configuration)
--
