Troubleshooting
156
Table 10-8 Information in message text output when the XP Provisioning Manager server receives
a request or sends a response
Item Description
unique-ID
Displays a unique value as the ID that identifies a request or response.
details-of-request
Displays a character string as the details of a request to the XP
Provisioning Manager server. For the meaning of the character string
displayed as the details of a request, see section
10-4-3 .
parameter
Displays the parameter information for identifying the target resource,
from among the parameters that are passed when a request is issued.
If there are no parameters, this information is not displayed. For details
about the parameters that are displayed, see section 10-4-3 .
The format for output parameters is as follows:
• A parameter is displayed in the format: info='...'. If there are
multiple parameters, each parameter is separated by a comma (,).
Such as: info='X,Y,Z'.
• If a parameter is an array, each value in the array is separated by a
space and the entire array is enclosed in square brackets, such as:
[a1 a2 a3].
• If a parameter value contains a single quotation mark ('), comma
(,), or square brackets ([]), the relevant symbol is replaced with a
question mark (?).
command-ID
Displays the ID that is assigned to an operation so that the logs related
to the operation can be identified.
The format for output command-IDs is as follows:
• A command ID is displayed in the format CID=....
• A command ID is not displayed when you register or view a license.
• Except for the above case, if a command ID cannot be obtained,
the character string Unknown is displayed.
status
Displays a character string that indicates the polling results. Some XP
Provisioning Manager operations take a long time to finish after a
request is issued. In this case, the processing status is checked by a
polling operation.
One of the following character strings is displayed:
• COMPLETED: The processing was completed.
• FAILED: The processing failed.
• SUSPENDED: The processing was suspended.
error-code
Displays the message ID.
operation-ID
Output character string that shows that the log before the operation
was interrupted is related to the log after the operation resumes.
This item is displayed in the following situations:
• When a response for a setting operation is sent (during normal
processing)
• When a response for polling is sent (during normal processing)
• When a response for polling is sent (during abnormal processing)
The following examples show output message text.
Example of message text output when XP Provisioning Manager receives a request (if no error
occurred):
"PvM123456789 GetAlloc info='32' CID=Pv243488034G"
Example of message text output when XP Provisioning Manager sends a response (if an error
occurred):
"PvM123456789 CID=Pv243488034G KARF15000-E"
