Troubleshooting
151
Table 10-3 Information in message-portion
Item
*
Description
FQDN
Fully qualified domain name.
redundancy-identification-
information
Redundancy identification information.
agent-information
Agent information.
request-source-host
Host name of the request sender.
request-source-port-number
Port number of the request sender.
request-destination-host
Host name of the request destination.
request-destination-port-number
Port number of the request destination.
batch-operation-identifier
Serial number of operations through the program.
log-data-type-information
Fixed to BasicLog.
application-identification-
information
Program identification information.
reserved-area
Not output. This is a reserved space.
message-text
The contents vary according to the audit events.
Characters that cannot be displayed are output as asterisks
(*).
For details, see section 10-4-1 .
*
Some items are not output for some audit events.
Example of message-portion output for a login audit event:
CELFSS,1.1,0,KAPM01124-I,2006-05-15T14:08:23.1+09:00,HBase-
SSO,management-
host,Authentication,Success,uid=system,,,,,,,,,,,,BasicLog,,,"The login
process has completed properly."
Example of message-portion output for a request-received audit event of the Device Manager
server:
CELFSS,1.1,10,KAIC51000-I,2006-03-17T12:45:00.0+09:00,DvM_Srv, TestServer,
ConfigurationAccess,Success,uid=system,,,,,,,from=12.228.23.124,,,,,BasicLog
,DvM_GUI,,"123456789 ModPort<SA info='R500-14000'><Port
info='0,0,,,1,,'></Port></SA>"
Example of message-portion output for a request-received audit event of the XP Provisioning
Manager server:
CELFSS,1.1,0,KARF91200-I,2006-11-0T18:21:17.9+09:00,PvM,CZA92G,Configuration
Access,Success,uid=System,,,,,,,from=10.208.64.128,,,,,BasicLog,PvM,,
"PvM123456789 GetSPoolSum info='All Resources' CID=Pv1163150475209G"
10-4-1 Message text in audit log data
The format of message text in output audit log data varies from one audit event to another. This
section describes the format of the message text for each audit event. The item enclosed by square
brackets ([ ]) in the format might not be output.
10-4-1-1 Message text output for XP Command View AE Common
Component processing
Information about audit event that occurred is output in a character string. The following shows an
example of message text.
