Troubleshooting
146
Table 10-2 Device Manager maintenance information
Log type Log name Description Location
(Windows)
Location (Linux)
Common trace
log file
hntr2n.lo
g
Integrated trace log
information produced by
Common Component. The n
in the file name indicates the
backup generation number
of the file. For details on
specifying the number and
size of files, see section 6-1
.
The characters below will be
output after being converted
as follows if they are
contained in a message
whose error code is in the
range from KAIC00000 to
KAIC09999:
• Line feed character:
Converted to an at mark
(@).
• At mark (@): Converted
to \@.
program-files-
folder\Hitachi\H
NTRLib2\spool
/var/opt/hitachi
/HNTRLib2/spool
Event log Windows event log (includes
audit log data). For details
on audit log data, see
section
10-4 .
Event viewer N/A
Event log/syslog
file
syslog Linux system log (includes
audit log data). For details
on audit log data, see
section
10-4 .
N/A Defined by
/etc/syslog.conf
