Setting up logs and alerts
105
Table 6-9 Items specified in the customizedsnmptrap.customizelist property
Item Format Remarks
message
Specify message information to be output
by using the character strings (variables)
below.
You cannot use character strings other
than the following:
• $a
• $e
• $g
• $s
• $n (where n indicates an integer,
which is 1 or larger)
Optional. If you omit this item, the
$a$e$g$s content is output.
If you specify Null for the severity,
specification for this item is
disabled.
Information output for each
variable is as follows:
• $a: Agent address (dotted
format)
• $e: Enterprise ID (dotted
format)
• $g: Generic trap number
• $s: Specific trap number
• $n (where n indicates an
integer, which is 1 or larger):
The value of the nth variable is
binding
The following shows the syntax of the customizedsnmptrap.customizelist property:
customizedsnmptrap.customizelist = \
enterprise-ID-1:generic-trap-number-1:specific-trap-number-1:
severity-1:message-1, \
enterprise-ID-2:generic-trap-number-2:specific-trap-number-2:
severity-2:message-2, \
...
enterprise-ID-n:generic-trap-number-n:specific-trap-number-n:
severity-n:message-n
• You can omit some items, but you cannot omit the colon delimiter.
• To specify more than one customization definition, use a comma as a delimiter, but do not
enter a comma at the end of the last entry.
• To move to a new line in the customization list, enter a back slash (\) at the end of that line.
The line feed following the back slash (\) is ignored.
The following shows an example of specifying the customizedsnmptrap.customizelist
property:
customizedsnmptrap.customizelist = \
.1.2.3:6:1:Information:$a$e$g$s$1$2, \
.1.3.6.1.4.1.2854:6:1:Warning:$e$a$s$3$2$1$g, \
.1.3.6.1.4.1.116.3.11.4.1.1:6:1:Error:$a$s, \
.1.3.6.1.4.1.116.3.11.4.1.1:6:100:Information:$a$s
6-4 Settings required for email notification
The email notification function notifies users, by email, of the contents of alerts that occurred in the
storage subsystem and were detected by the Device Manager server.
To use this function, you need to specify settings at the SMTP server, for the Device Manager
users, and at the Device Manager server.
For the email notification function, the Device Manager server notifies users of an alert only once
when the Device Manager server detects the alert. If the Device Manager server fails to send an
email, the same email will not be sent again. Information on an alert for which the Device Manager
server fails to send an email, as well as the email address of the intended destination of this email,
