• AddPool, page 72
• GetStorageArray (subtarget=Pool) , page 165
• ModifyExternalTierRank, page 187
• ModifyPool, page 193
Table 140 PoolTier instance attributes
DescriptionAttribute
Object ID of the hardware tier
objectID
Name of the hardware tier
name
ID of the hardware tier
tierID
Capacity of the hardware tier (KB)
This value does not match the total capacity of the Smart pool volumes because
the pool of Smart Tiers uses a control area.
capacityInKB
Unused capacity of the hardware tier (KB)
freeCapacityInKB
Usage rate of the hardware tier
usageRate
RAID level (example: RAID6 or RAID1+0)
Unknown is output if any of the following conditions are satisfied:
• RAID level is unknown
• RAID levels are mixed
• RAID configurations with different combinations of data drives and parity drives
are mixed
raidLevel
Combination of data drives and parity drives in a RAID configuration.
This item is output as xD+yP or as xD+xD.
• xD: Number of data drives
• yP: Number of parity drives
Unknown is output if any of the following conditions are satisfied:
• The combinations of data drives and parity drives are unknown
• The combinations of data drives and parity drives are mixed
• RAID levels are mixed
combination
Drive revolutions per minute
-1 is output if any of the following conditions are satisfied:
• The drive speed is unknown
• Drives with different drive speeds are mixed
• Drive types are mixed
rpm
