Settings required for linking with related products
90
5-3-3 Starting Device Manager web client from HP SIM
To start web client of Device Manager from HP SIM:
1. Log in to HP SIM as a user who is to use Device Manager.
2. Select Tools, Command View and then XP Command View AE.
3. Select the server onto which Device Manager was installed, and then select Apply.
4. Select Run Now to start web client of Device Manager.
Possible causes and actions to be taken when an authentication error occurs:
The following table lists and describes the possible causes and actions to be taken when an
authentication error occurs during startup of the Device Manager web client.
Table 5-4 Possible causes and actions to be taken when authentications error occurs
Cause Action
Upper limit of single sign-on
requests was exceeded.
Check the following log file generated by Common Component to make sure
there is no unauthorized access. The n in the file name indicates a file
number:
• In Windows:
installation-folder-for-Common-
Component\log\HpsimSSOn.log
• In Linux:
/var installation-directory-for-Common-
Component/log/HpsimSSOn.log
If there is no unauthorized access, wait about 5 minutes, and then log in
again.
The imported HP SIM
certificate was incorrect or
old.
Delete the imported HP SIM certificate, and then reimport the latest HP SIM
certificate. To delete the HP SIM certificate, execute the following command:
•
In Windows:
installation-folder-for-Common-
Component\bin\hcmdshpsimcert /delete /host host-name-
of-the-HP-SIM-server
• In Linux:
installation-directory-for-Common-
Component/bin/hcmdshpsimcert -delete -host host-name-
of-the-HP-SIM-server
For host-name-of-HP-SIM-server, you can specify a logical host name or an
IP address.
5-4 Settings for starting applications from web
client
When you select Go and then Links in the global tasks bar area of web client, a dialog box is
displayed with links for starting applications for which the user is registered. By registering the web
applications that you often use or the information that you want to reference (such as a device
installation chart) to this window, you can easily call a desired application from web client. To
register a desired application or cancel the registration, you use the hcmdslink command. This
section describes how to use the hcmdslink command.
Format:
In Windows:
installation-folder-for-Common-Component\bin\hcmdslink {/add | /delete
} /file user-defined-application-file [/nolog] /user user-identifier
/pass password
