Settings for various network configurations
71
Format:
In Windows:
installation-folder-for-Common-Component\bin\hcmdschgurl {/print |
/list | /change old-URL new-URL | /change new-URL /type XP-Command-
View-AE-Suite-product-name}
In Linux:
installation-directory-for-Common-Component/bin/hcmdschgurl {-print |
-list | -change old-URL new-URL | -change new-URL -type XP-Command-
View-AE-Suite-product-name }
Options:
print: Specify this option to display a list of URLs and programs that are currently registered.
list: Specify this option to display the same information as the print option in a different
format.
change: Specify this option to change a currently registered URL.
CAUTION:
•
The specified URL must be a complete URL that contains protocols and port number. You cannot use an
IPv6 address. You must use a host name to specify the URL in an IPv6 environment, as shown in the
following example:
http://127.0.0.1:23015
http://hostname:23015
• When changing the URL during migration to a cluster environment, use the following format to specify
new-URL:
http://logical-host-name:port-number
type: If you want to change the URL for a specific XP Command View AE Suite product only,
use this option to specify the name of that product. If you omit the type option, the URLs for all
XP Command View AE Suite products that are installed in the same management server will
be changed. To change only the Device Manager URL, specify DeviceManager. To change
only the XP Provisioning Manager URL, specify ProvisioningManager. For details on the
names of other XP Command View AE Suite products, see the documentation for each
product.
Return values:
1: Argument error
2: URL does not exist
253: Restoration failure
254: Backup failure
255: Abnormal termination
For details about the errors, check a following log file:
○ In Windows:
installation-folder-for-Common-Component\log\hcmdsChangeURLn.log
○ In Linux:
/var/installation-directory-for-Common-
Component/log/hcmdsChangeURLn.log
To change the URLs for accessing XP Command View AE Suite products:
1. Make sure that the Common Component services are running.
○ In Windows:
