Settings for various network configurations
69
○ If a host name has been specified for the <VirtualHost> tag, change the host name to
an asterisk (*).
○ Change the value for the ServerName parameter in the <VirtualHost> tag to the new
host name.
6. Edit the pdsys file and the def_pdsys file.
Change the value for the pdunit parameter's -x option to the loopback address 127.0.0.1.
The pdsys and def_pdsys files are stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\pdsys
installation-folder-for-Common-Component\database\work\def_pdsys
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/pdsys
installation-directory-for-Common-Component/database/work/def_pdsys
7. Edit the pdutsys file and the def_pdsys file.
Change the value for the pd_hostname parameter to the loopback address 127.0.0.1. If the
pd_hostname parameter does not exist, add the pd_hostname parameter, specifying the
loopback address.
The pdutsys and def_pdutsys files are stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\pdutsys
installation-folder-for-Common-Component\database\work\def_pdutsys
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/pdutsys
installation-directory-for-Common-
Component/database/work/def_pdutsys
NOTE: If the management server is running in a cluster configuration, you also need to change
the settings in the pdutsys file and the def_pdutsys file on the standby node. For the
pd_hostname parameter on the standby node, specify the loopback address 127.0.0.1 or the
host name of the executing node.
8. Edit the HiRDB.ini file.
Change the value for the PDHOST parameter to the loopback address 127.0.0.1.
The HiRDB.ini file is stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\emb\HiRDB.ini
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/emb/HiRDB.ini
9. Edit the cluster.conf file (only for a cluster configuration).
Change the corresponding logical host name, executing node's host name, and standby node's
host name to the new host names.
The cluster.conf file is stored in the following location:
installation-folder-for-Common-Component\conf\cluster.conf
10. Change the host name for the management server, and then restart the computer.
If you have changed the host name for the management server before changing the Common
Component settings files, just restart the computer.
11. Make sure that the Common Component services are running.
