Settings for various network configurations
67
○ In Linux:
installation-directory-for-Common-Component/httpsd/conf/httpsd.conf
NOTE: HP recommends that you specify the host name in the httpsd.conf file.
4. Edit the pdsys file and the def_pdsys file.
If the old IP address is specified in the pdsys file and the def_pdsys file, change the IP
address to the loopback address 127.0.0.1.
The pdsys and def_pdsys files are stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\pdsys
installation-folder-for-Common-Component\database\work\def_pdsys
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/pdsys
installation-directory-for-Common-Component/database/work/def_pdsys
5. Edit the pdutsys file and the def_pdutsys file.
If the old IP address is specified in the pdutsys file and the def_pdutsys file, change the IP
address to the loopback address 127.0.0.1.
The pdutsys and def_pdutsys files are stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\pdutsys
installation-folder-for-Common-Component\database\work\def_pdutsys
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/pdutsys
installation-directory-for-Common-
Component/database/work/def_pdutsys
NOTE: If the management server is running in a cluster configuration, you also need to change
the IP address specified in the pdutsys file and the def_pdutsys file to the loopback address
127.0.0.1 on the standby node .
6. Edit the HiRDB.ini file.
If the old IP address is specified in the HiRDB.ini file, change the IP address to the loopback
address 127.0.0.1.
The HiRDB.ini file is stored in the following locations:
○ In Windows:
installation-folder-for-Common-Component\HDB\CONF\emb\HiRDB.ini
○ In Linux:
installation-directory-for-Common-Component/HDB/conf/emb/HiRDB.ini
7. Change the IP address of the management server, and then restart the computer.
If the IP address of the management server has already been changed before you change the
Common Component settings files, just restart the computer.
8. Make sure that the Common Component services are running.
○ In Windows:
Select Start > All Programs > XP Command View AE > Device Manager > Server and
Common Services Status.
○ In Linux:
