Settings for various network configurations
63
5. After returning to the Firewall Configuration window, check that Security Level is Enabled, use
the tab key to move to OK, and then press Enter.
2-1-4-2 In SUSE Linux Enterprise Server
To register a firewall exception by using SuSEFirewall2:
1. Edit the /etc/sysconfig/SuSEfirewall2 file to specify the port to be registered as an
exception.
Specify the port numbers to be registered as exceptions, in the following format:
○ FW_SERVICES_EXT_TCP="TCP-port-number"
○ FW_SERVICES_EXT_UDP="UDP-port-number"
Example: In this example, 2001, 23015, 23016, 23017, 23018, 161, and 162 are registered
as exceptions.
FW_SERVICES_EXT_TCP="2001 23015:23018"
FW_SERVICES_EXT_UDP="161 162"
2. Execute /sbin/SuSEfirewall2.
2-2 Settings required to use a management
server that has multiple NICs
If the server computer on which Device Manager server has been installed has multiple NICs and
uses the bridge function, when you specify an IP address in the Device Manager settings, specify
the IP address of the NIC that belongs to the network to which web client is connected. Do not
specify the host name.
The following describes the network settings required for the configuration example in the figure
below.
Figure 2-1 Configuration example using a server computer that has two NICs
