Settings for various network configurations
58
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and management clients.
Table 2-4 Port numbers that must be registered as exceptions to a firewall between the
management server and management clients
Port number Originator Destination Remarks
2001/tcp
*
Management client
(web client or CLI)
Management server This setting is required when
non-SSL communication is
used.
2443/tcp
*
Management client
(web client or CLI)
Management server This setting is required when
SSL communication is used.
23015/tcp
*
Management client
(web client)
Management server This setting is required when
non-SSL communication is
used.
23016/tcp
*
Management client
(web client)
Management server This setting is required when
SSL communication is used.
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and storage subsystems.
Table 2-5 Port numbers that must be registered as exceptions to a firewall between the
management server and storage subsystems
Port number Originator Destination Remarks
20/tcp
•
XP512/XP48
• XP1024/XP128
• XP12000/XP10000/S
VS200
• XP24000/XP20000
Management server Set up the firewall so that
communication can be
established from the 20/tcp port
of the storage subsystem to
any port of the management
server.
21/tcp
Management server
• XP512/XP48
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
161/udp
Management server XP512/XP48 -
162/udp
• XP512/XP48
• XP1024/XP128
• XP12000/XP10000/S
VS200
• XP24000/XP20000
Management server -
1099/tcp
Management server
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
2001/tcp
*
• XP12000/XP10000/S
VS200
• XP24000/XP20000
Management server Set up the firewall so that
communication can be
established from any port of the
storage subsystem to the
2001/tcp port of the
management server.
