Settings for various network configurations
54
2-1-1-3 Ports used by Device Manager agent
The following table describes the ports used by a Device Manager agent.
Table 2-3 Ports used by Device Manager agent
Port number Description
24041/tcp Used for communication with the Device Manager
server.
You can change the port by using the
server.agent.port property in the
server.properties file of the Device Manager
agent.
XP mainframe agent can also use this port.
24042/tcp Used for communication with the Device Manager
server.
You can change the port by using the
server.http.port property in the
server.properties file of the Device Manager
agent.
XP mainframe agent can also use this port.
24043/tcp Used internally for Device Manager agent
communication.
You can change the port by using the
server.http.localPort property in the
server.properties file of the Device Manager
agent.
2-1-1-4 Ports used by storage subsystems
If you change the port number used by a storage subsystem, you need to specify the new port
number in the services file of the management server OS. If you operate the storage subsystem
without doing so, an error (code: DMEA000006) occurs and operations might fail.
For communication between storage subsystems and the Device Manager server, use the same
port number for SSL and non-SSL communication. If communication is between storage
subsystems that have different port numbers, an error might occur if a storage subsystem uses a
port number that is different from the one specified in the services file of the management server.
In addition, even if the storage subsystems use the same port numbers as the ones specified in the
services file, an error will not occur but the operation might take a long time.
For details about how to check the port numbers and how to specify entries in the services file,
see the documentation for each storage subsystem.
2-1-2 Changing ports used by Common Component
After installing Device Manager, if you want to change any of the ports used by Common
Component, use the following procedure:
1. If XP Command View AE Suite products whose versions are earlier than 5.7 are running, stop
their services.
For details about how to stop these services, see the manual for your product version.
2. Stop the services of XP Command View AE Suite products and Common Component.
○ In Windows:
Select Start > All Programs > XP Command View AE > Device Manager > Stop Server
with Common Services.
