Overview
32
Table 1-16 Prerequisite firmware versions and software for XP12000/XP10000/SVS200
Prerequisite firmware versions Prerequisite software products
• SVP microcode : 50-07-69-00/00 or later
• Controller microcode to use the XP
Disk/Cache Partition view function:
50-03-xx-xx/xx or later
• Controller microcode to use an XP
Continuous Access Journal function:
50-09-85-xx/xx or later
• Controller microcode to use XP External
Storage Software to view the setting status of
a remote command device:
50-07-00-xx/xx or later
• Controller microcode to use 3DC functionality:
50-08-00-xx/xx or later
• Controller microcode to use the function that
allows LU creation and LU formatting to be
performed separately:
50-09-00-xx/xx or later
• Controller microcode to use the function for
acquiring the status of an LDEV:
50-09-00-xx/xx or later
• Java API
• HP SNMP API
• XP LUN Manager
• XP Remote Web Console
To use functions for creating a LUSE or LDEV
(CVS):
• XP Virtual LVI/LUN (VLL) and Volume
Shredder
To use copy pair functionality:
• HP StorageWorks XP Business Copy
Software
• Hitachi ShadowImage for Mainframe
Software
*
• HP StorageWorks XP Continuous Access
Synchronous Software
• Hitachi TrueCopy for Mainframe Software
*
• HP StorageWorks XP Continuous Access
Asynchronous Software
• Hitachi TrueCopy Asynchronous for
Mainframe Software
*
• HP StorageWorks XP Continuous Access
Journal
• Hitachi Universal Replicator for Mainframe
Software
*
• HP StorageWorks XP Snapshot
*
• Controller microcode to use the performance
information acquisition feature:
50-09-34-xx/xx or later
• Controller microcode to use 19 VMware as
the host mode option:
50-09-00-xx/xx or later
• Controller microcode to use 27 iSCSI
Delayed ACK improvement as the host
mode option:
50-09-37-xx/xx or later
• Controller microcode to use 23 REC Command
Support as the host mode option:
50-09-7x-xx/xx or later
To link with NAS Manager:
• NAS Blade Manager
To use external storage:
• HP StorageWorks XP External Storage
Software
To use storage logical partitioning (SLPR) or
cache logical partitioning (CLPR):
• HP StorageWorks XP Disk/Cache Partition
Manager
*
From Device Manager, you can only check configuration information of copy pairs. You cannot
change the copy pair configuration.
