Overview
31
Table 1-15 Prerequisite firmware versions and software products for XP24000/XP20000
Prerequisite firmware versions Prerequisite software products
• Controller microcode to use XP External
Storage Software for mapping external
volumes to internal volumes:
60-02-4x-xx/xx or later
• Controller microcode to use XP External
Storage Software for removing the mapping
between external and internal volumes:
60-06-00-xx/xx or later
• Controller microcode to manage storage
subsystems by using IPv6 addresses:
60-02-4x-xx/xx or later
• Controller microcode to use 23 REC Command
Support as the host mode option
60-02-24-xx/xx or later
• Controller microcode to use when the Device
Manager server periodically checks changes
in the XP24000/XP20000 configuration:
60-04-10-xx/xx or later
*
From Device Manager, you can only check configuration information of copy pairs. You cannot
change the copy pair configuration.
NOTE: Do not use DHCP (Dynamic Host Configuration Protocol) if you use Device Manager to
manage the storage subsystem.
1-4-2 System requirements for XP12000/XP1000/SVS200
The following table describes the prerequisite firmware versions and software products.
