Overview
22
Table 1-6 Installation folders and required disk space (in Windows)
Item Default installation folder Required disk
space
Output folder for common trace log
files
2, 3
program-files-
folder\Hitachi\HNTRLib2\spool
1.0 MB
A temporary folder
4
A folder specified by the environment variable TMP
0.3 GB
NOTE: If the architecture is x86, program-files-folder and common-program-files-folder are
the folders specified in the Windows environment variables %ProgramFiles% and
%CommonProgramFiles%. By default, these folders are as follows:
system-drive\Program Files\
system-drive\Program Files\Common Files
If the architecture is IPF or x64, program-files-folder and common-program-files-folder are the
folders specified in the Windows environment variable %ProgramFiles(x86)% and
%CommonProgramFiles(x86)%. By default, these folders are as follows:
system-drive\Program Files(x86)\
system-drive\Program Files (x86)\Common Files
1
If you are installing the Device Manager server in an environment where Common Component has already
been installed, install it on the same drive.
2
This is not required if an XP Command View AE Suite product has already been installed.
3
You can change the size and number of generations of common trace log files. For details about how to do
this, see section
6-1 .
4
This is required only during installation, and is unnecessary after installation.
1-3-1-2 Requirements when using Linux as the management server OS
The following table lists the OSs that can be used on a management server in a Linux environment.
Table 1-7 Usable management server OSs (Linux)
OS Version Architecture Cluster
environment
support
IPv6
environment
support
Red Hat Enterprise
Linux AS 4
Red Hat Enterprise
Linux ES 4
Update4 x86 -- Y
4.5 x86 -- --
4.6 x86 -- --
4.7 x86 -- Y
