Appendix A Specifying properties
192
true. To not use SMTP authentication, set this property to false. Specifying this property is
optional.
Default: false
A-2-37 server.mail.alert.type
This property specifies the type of alerts to be reported by the email notification function of the
Device Manager server. The following values can be specified:
Trap: Reports only SNMP trap alerts.
Server: Reports only the alerts detected by the background threads responsible for checking
component status and the configuration version.
All: Reports both SNMP trap alerts and the alerts detected by the background threads responsible
for checking component status and the configuration version.
NOTE: If All is set, alerts are reported from both SNMP and the server even if these alerts refer
to the same error information.
Default: Trap
A-2-38 server.mail.alert.status
This property specifies the severity of alerts to be reported by the email notification function of the
Device Manager server. The Device Manager server reports alerts whose severity is higher than the
severity specified for this property. The following values (listed in ascending order of importance)
can be specified:
Normal, Service, Moderate, Serious, Acute
Default: Moderate
A-2-39 server.subsystem.ssid.availableValues
This property specifies the range of the SSIDs that can be assigned automatically to storage
subsystems registered in Device Manager.
This property is valid for the XP1024/XP128 series, XP12000/XP10000/SVS200, and
XP24000/XP20000.
The values that can be specified for this property are as follows:
Hexadecimal numbers in the range from 4 to FFFD: To specify consecutive numbers, use a hyphen
(-) to specify the range. To specify nonconsecutive numbers, use commas as separators. The
values are not case sensitive. If multiple values and ranges that include duplicated numbers are
specified, the logical union of all specified values is used.
All: The string All specifies that the entire range of values can be specified. This value is not case
sensitive.
Automatic SSID assignment can be performed only when a value or values are specified in this
property.
Default: All
A-2-40 server.smisclient.indication.port
This property specifies the port number used to receive event indications from SMI-S providers.
Specifiable range: 1024 to 49151.
