Overview
19
Table 1-3 Virtual machine OSs on which the Device Manager server can run (Windows)
Virtual machine Virtualization software
OS Edition Service pack VMware ESX
1
Hyper-V
2
HP Integrity
VM
3
Windows Server
2008 R2
(x64)
Datacenter
Edition
Enterprise
Edition
Standard Edition
No SP Y Y --
Windows XP Professional SP2 Y -- --
SP3 Y -- --
Windows Vista
(x86)
Business
Enterprise
Ultimate
No SP Y -- --
SP1 Y -- --
SP2 Y -- --
Windows 7
(x86)
Enterprise
Edition
Professional
Edition
Ultimate Edition
No SP Y -- --
Windows 7
(x64)
Enterprise
Edition
Professional
Edition
Ultimate Edition
No SP Y -- --
Legend
Y: Supported.
--: Not supported.
NOTE: To run the Device Manager server on a virtual machine, configure the virtual machine to satisfy the
requirements in
Table 1-4.
1
Version 3.x or 4.x can be used.
2
Version 1.0 or 2.0 can be used.
3.
Version 4.1 can be used.
The following table lists the requirements for a management server computer in a Windows
environment.
Table 1-4 Computer requirements (Windows)
Item Requirements
Processor Minimum:
1.0 GHz
Recommended:
2.0 GHz or faster
