Troubleshooting
178
Table 10-17 Details of requests and parameters output as XP Provisioning Manager server audit
log data
Request Description Output parameter
StartAddFSys
Creates a file system.
• Resource identifier of the
target host
2
• Resource identifier of the
target volume
2
• Type of the file system to be
created
• Mount point of the file system
to be created
• Type of the volume manager
to be used
• Volume group name
• Logical volume name
CAUTION: The volume group
name and logical volume name
are displayed only when they are
specified.
StartDelDevF
Deletes a specified device file. Resource identifier of the device
file to be deleted
2
StartDelFSys
Deletes a specified file system. Resource identifier of the file
system to be deleted
2
StartExpandFSys
Expands a file system.
• Resource identifier of the file
system to be expanded
2
• Resource identifier of the
target volume
2
1
For details about the parameters output as information about the allocation plan, see Table 10-18. The
allocation plan information is displayed enclosed in square brackets ([]), and values are separated by a
semicolon (;).
2
The resource identifier consists of several elements. For details about the elements of each resource
identifier, see
Table 10-19. The elements of each resource identifier are output, separated by a hyphen (-).
Table 10-18 Parameters output as information about the allocation plan
Output
Information about the
allocation plan
ModAllocPl Other than ModAllocPl
Plan name Y Y
Model name of storage subsystem Y Y
RAID level Y Y
Plan creation date Y --
Plan owner resource group Y --
User who created the plan Y --
Plan creation resource group Y --
Plan update date and time Y --
User who updated the plan Y --
Plan update resource group Y --
Plan status (public or private) Y --
Legend: Y: Output, --: Not output
