Troubleshooting
171
Table 10-14 Sequence in which attributes values are output for each element in a detail
message
Output
character string
Full name and content Sequence in which Attribute values are
output
1
WorldWideName, nickname, operation target host
storage domain name
WWN
WorldWideName
(Host HBA information)
wwn, nickname, targetNickname
<model name
2
- serial number - port ID - nickname
of WWN group>, nickname, name
WWNGrp
WWNGroup
(Groups WWNs)
<model
2
- serialnum - portID - nickname>,
nickname, name
Legend:
--: No attribute value is output
<...>: An element identifier that represents an attribute. If the contents include multiple elements, they are
concatenated by a hyphen (-).
1
The lower field of each element indicates the output order represented with the names used within
Device Manager.
2
This information is output as the storage subsystem model, and is the common output name indicated in
Table 10-15 .
3
This information is output as the ObjectName element <target element identifier>. The attribute value is
not output as a rule.
4
For XP24000/XP20000, a numerical value that combines the LDKC number, CU number, and LDEV
number (= LDKC x 65536 + CU x 256 + LDEV) is output. For XP512/XP48, XP1024/XP128, or
XP12000/XP10000/SVS200, a numerical value that combines the CU and LDEV numbers (= CU x 256 +
LDEV) is output. For the LU number is output.
5
The replication operation type attribute is represented by the common output name indicated in Table
10-16
when it is output.
Table 10-15 Common output names for storage subsystem models
Common output
name
Applicable storage subsystem model
R400 XP512/XP48
R450 XP1024/XP128
R500 XP12000/XP10000/SVS200
R600 XP24000/XP20000
Table 10-16 Common output names for replication operation type
attributes
Common output
name
Applicable product
Local Copy XP Business Copy Software
Remote Copy (Async) XP Continuous Access Asynchronous
Remote Copy (Jrnl) XP Continuous Access Journal
Remote Copy (Sync) XP Continuous Access Synchronous
