Troubleshooting
164
Table 10-14 Sequence in which attributes values are output for each element in a detail
message
Output
character string
Full name and content Sequence in which Attribute values are
output
1
<host name - host SCSI bus number - target ID - LU
number of volume on host>, type (model
2
) of
storage subsystem connected with host, serial
number of storage subsystem connected with host,
displayed name of HostInfo object, host IP address,
host IP address for IPv6, LUN mount point, port ID,
domain ID of host storage domain, device number of
logical unit
4
, port WWN on HBA, type of file system
to be mounted, file system name, LUN capacity,
LUN usage
HostI
HostInfo
(Information about
accesses between the LU
and host)
<name - osScsiBus - osScsiID - osLun>,
arrayType
2
, serialNumber, name, ipAddress,
ipv6Address, mountPoint, portID, domainID,
devNum
4
, portWWN, fileSystemType,
fileSystemName, sizeInMB, percentUsed
device file name, vendor name, model name
2
, serial
number, port number, device number
4
, identification
number, host name,, IP address, host IP address for
IPv6, mount point, SCSI bus number, SCSI bus
connection identification number, LU number, WWN
of HBA node, WWN of HBA port, WWN of storage
subsystem port, file system type, file system name,
volume size, volume usage, LU pair type, device file
name managed by Hitachi Dynamic Link Manager,
number of paths managed by Hitachi Dynamic Link
Manager, LU pair type (XP Continuous Access
Journal), number of paths managed by path
management software other than Hitachi Dynamic
Link Manager, device file name managed by path
management software other than Hitachi Dynamic
Link Manager, iSCSI name of iSCSI initiator,
inquiry's host group ID (0 to 254)
HostVol
HostVolume
(Volume information
obtained from the Device
Manager agent)
deviceFileName, vendorID, model
2
, serialNumber,
port, devNum
4
, hsDeviceID, name, , ipAddress,
ipv6Address, mountPoint, OSscsiBus, OSscsiID,
OSlun, hbaWWN, portWWN, subsystemPortWWN,
fileSystemType, fileSystemName, sizeInMB,
percentUsed, pairType, dlmPathName,
numberOfDlmPath, pairTypeTCMirror,
numberOfPath, relatedPathName, portISCSIName,
hostGroupID,
<model name
2
- serial number - port ID - domain
ID>, port ID, domain ID, new host connection mode
for host storage domain, list of new host connection
modes, host connection mode options, host storage
domain name, nickname of host storage domain,
operation target host storage domain name,
operation target host storage domain port ID,
domain type of host storage domain
HSD
HostStorageDomain
(Information about the host
storage domain)
<model
2
- serialnum - portID - domainID>, portID,
domainID, hostMode, hostMode2, hostModeOption,
name, nickname, targetNickname, targetPortID,
domainType
IPAddress
IPAddress
(The IP address of the port
controller)
--
