Troubleshooting
162
Table 10-14 Sequence in which attributes values are output for each element in a detail
message
Output
character string
Full name and content Sequence in which Attribute values are
output
1
LDEV information version, port information version,
LU information version, LUSE information version,
LUN information version, host mode information
version, DCR information version, CVS information
version, SSID information version, CHA information
version
ChangeI
ChangeInfo
(Version information of the
storage subsystem
configuration)
versionOfLDEV, versionOfPort,
versionOfLogicalUnit, versionOfLUSE,
versionOfLUNSecurity, versionOfHostMode,
versionOfDCR, versionOfCVS, versionOfSSID,
versionOfCHA
Object path for service class whose method is
executed
CIMIvk
CIMInvoker(Element for
identifying the CIM
instance)
objectPath
CommandComplet
e
CommandComplete
(Information required by
clients when the Get
Request Status
command is issued)
--
CommParas
CommParameters
(Information about how to
access the storage
subsystem)
--
Comp
Component
(Information about the
storage subsystem
configuration)
--
LU type, element identifier of LDEV, LDEV type,
host storage status, Alert source, host type, CLPR
number of journal volume, element identifier of host ,
journal pool identifier, THP pool volume ID, volume
accessible from the specified WWN, type of LDEV
(whether it is an internal volume or an assigned
volume), object ID of target storage subsystem,
MCU model, serial number of MCU
Cond
Condition
(Limits the results of the
Get command by using the
Filter elements at the same
time)
type, childID, volumeKind, host, source, hostType,
clprNumber, assocID, poolFunction, thpPoolID,
accessibleWWN, substance, targetArray,
masterArrayType, masterSerialNumber
user ID, notification type, serial number, product
name
2
, occurrence date and time, IP address
ConfChange
ConfigurationChange
(Reports information about
the configuration changes
of the storage subsystem to
the Device Manager server)
user, type, serialNumber, arrayType
2
, date,
ipAddress
ConfigChange
ConfigChange
(Information about the data
changed in the Device
Manager server)
--
<host ID - HORCM instance number>
ConfigF
ConfigFile
(Information about the XP
RAID Manager
configuration file)
<host ID - instanceNumber>
DataRetention
DataRetention
(Data retention information)
--
