Troubleshooting
160
Table 10-12 Targets output in detail messages
Output
character
string
Full name Operation
ZPRVol
ZeroPageReclaimVolume Information acquisition about the progress of a zero
data discard task for the target THP volume
The table below provides the contents of options that can be output in detail messages.
Table 10-13 List of options in detail messages
Output character
string
Operation
add
Adds a logical path to an existing RCU.
all
• If the target is StorageArray
Also obtains information on an SMI-S Enabled subsystem.
• If the target is URLLink
Also obtains the URL of the management server for an SMI-S
Enabled subsystem.
assign
Associates a pool with a virtual volume.
bulk
Creates the specified number of volumes or multiple volumes of the
specified size.
datastore
Updates only the information about the data store capacity on the
virtualization server.
delete
Deletes a logical path from an existing RCU.
dividebycap
Creates multiple volumes of the specified size.
dividebynum
Creates the specified number of volumes.
exist
Creates a virtual volume in an existing virtual volume group.
force
• If the target is LUSE
Creates an LUSE in the logical unit that already has paths.
• If the target is Virtual Volume
The virtual volume associated with a pool is disassociated from the
pool and deleted.
lusekeep
Keeps the LUSE.
merge
Merges the WWNs assigned to multiple hosts into one host.
noformat
Creates a logical unit without formatting.
nolabelbefore
Assumes an error if a label has already been set.
numOfLUs:n
Specifies the number of volumes or virtual volumes to be created
(indicated by n).
overwrite
Deletes the current label and then sets a new label.
quickformat
• If the target is LogicalUnit
Creates and quickly formats a logical unit.
• If the target is LogicalUnitFormat
Quickly formats a logical unit.
remainMigraion
Leaves the plan status of the completed plan in the subsystem (SVP).
restore
Copies the data of the secondary volume to the primary volume.
resync
Copies the data of the primary volume to the secondary volume.
