Troubleshooting
157
10-4-2 Detail message output for a request to a Device
Manager server
This section describes the format of, and information in, a detail message that is output when the
Device Manager server receives a request. The item enclosed by square brackets ([ ]) in the output
format might not be output.
Format of an output detail message:
command target[ option][ parameter]
Table 10-9 Information output in detail messages
Item Description
command
A character string (3 characters) that indicates the operation (for
example, addition, deletion, modification, or reference) to be
performed on the resource. For the meaning of the output character
string, see
Table 10-11.
target
Information that identifies the operation to be performed. For
information on the target to be output in the message text, see
Table 10-12. However, Table 10-12 might not contain some displayed
characters.
option
Format: [...]
Information that identifies the operation to be performed. This
information is output only when one or more options are specified.
For more information on the meanings of output options, see
Table
10-13
.
If two or more options are specified, a semicolon (;) is used as a
separator.
parameters
Information that identifies the operation to be performed and the
resource on which the operation is to be performed. (This
information is output only when it is specified by request.) This
information is output in tagged format.
The format and content of the parameters (parameter, above) output in detail messages are
described below.
Parameter format 1 (nested):
<element attribute>[parameter-1 parameter-2...parameter-n]</element>
The parameters that depend on the element are output between the start and end tags of element.
If no relevant parameters exist, no parameters are output.
Parameter format 2 (non-nested):
<element attribute/>
Table 10-10 Information output in detail message parameters
Item Description
element
A character string that indicates the element name. For information
on the elements that are output and their meanings, see Table 10-14.
However,
Table 10-14 might not contain some displayed characters
