Troubleshooting
155
Table 10-7 Information in message text output when the Device Manager server
receives a request or sends a response (for processing via CIM)
Item Description
input-parameter
Format: inParams={...}
The input parameters passed to the requested method are output.
object-path
Format: objectPath=...
The object path passed to the requested method is output.
return-code
Format: return=...
The return code that indicates the execution result of the requested
method is output.
output-parameters
Format: outParams={...}
The output parameters passed as the execution result of the
requested method are output.
The following examples show output message text.
Example of message text output when the Device Manager server receives a request for server
processing (via CIM, if no error occurred):
"1183371423687 GetSupportedSizeRange
inParams={ElementType=3,Goal=//192.168.0.1/root/smis/current:HITACHI_St
orageSetting.InstanceID='RAID5'}
objectPath=/root/smis/current:HITACHI_StoragePool.InstanceID='XP12000.6
3507'"
Example of message text output when the Device Manager server sends a response to a request
for server processing (via CIM, if no error occurred):
"1183371423687 return=0 outParams={MinimumVolumeSize=1024,MaximumVolume
Size=248139692,VolumeSizeDivisor=1024}"
10-4-1-5 Message text output for XP Provisioning Manager server processing
The XP Provisioning Manager server receives a request or sends a response, message text about
the request or response is output as audit log data. The following explains the format of, and
information in, the message text.
Format of message text output when the XP Provisioning Manager receives a request (if no error
occurred):
unique-ID details-of-request parameter command-ID
Format of message text output when the XP Provisioning Manager receives a request (if an error
occurred):
unique-ID details-of-request parameter command-ID error-code
Format of message text output as audit log data when the XP Provisioning Manager sends a
response (if no error occurred during a view or setting operation, or when either of those operations
was suspended):
unique-ID command-ID operation-ID
Format of message text output when the XP Provisioning Manager sends a response (if an error
occurred during a view or setting operation):
unique-ID command-ID error-code
Format of message text output when the XP Provisioning Manager sends a response (if no error
occurred during polling):
unique-ID command-ID status operation-ID
Format of message text output when the XP Provisioning Manager sends a response (if an error
occurred during polling):
unique-ID command-ID error-code operation-ID
