Troubleshooting
153
10-4-1-3 Message text output for launches of related products
When the Device Manager server receives a request to launch a related product or sends a
response for a request, message text about the request or response is output as audit log data. The
following explains the format of, and information in, the message text.
Format of message text output when the Device Manager server receives a request to launch a
related product (if no error occurred):
unique-ID[ launch-session-ID][ launch-target-identifier]
Format of message text output when the Device Manager server sends a response to a request to
launch a related product (if no error occurred):
unique-ID[ launch-session-ID]
Format of message text output when the Device Manager server receives a request to launch a
related product or sends a response (if an error occurred):
unique-ID[ launch-session-ID] error-message-ID
Table 10-5 Information in message text output when the Device Manager server receives
a request or sends a response (for launching a product)
Item Description
unique-ID
A unique request identifier. For response transmission, the unique ID
of the request is output. For processing via the SVP, this identifier is
also output as audit log data on the SVP.
launch-session-ID
Format: lsessionID=...
The launch session ID is output. This information is output when a
specific application is launched under the condition that request-
response exchange between the web client and the Device Manager
server is performed more than once. For information on the
applications for which the launch session ID is output, see
Table 10-6.
This item is not output when the subsystem to be launched is
XP24000/XP20000.
launch-target-
identifier
Format: loid=...
Information that identifies the launch target is output. This information
is output only when the first request is received. The information
contained in the launch identifier varies depending on the application
to be launched. For details, see Table 10-6.
error-message-ID
The ID of the error message.
The table below indicates the relationship between the presence of a launch session ID and the
information contained in the launch target identifier for each type of the application to be launched.
Table 10-6 Relationship between the presence of a launch session ID and the
information contained in the launch identifier
Application type Presence of
session ID
Information in launch Identifier
XP Remote Web Console Present
Physical View Not present
Information that identifies the subsystem to be
launched. The value is the same as an element
identifier
1
in the StorageArray element. For
more information, see the attribute value output
sequence for the StorageArray element in
Table 10-14.
2
Resource group
assignment
Not present An ID that indicates the dialog box is used to
manage resource groups of the user or used to
