Overview
15
NOTE: This configuration may be a requirement if the implementation cannot accommodate a
management LAN.
The following figure illustrates a flat network.
Figure 1-6 Least secure configuration: flat network
1-3 Management server requirements
This section describes the management server requirements.
1-3-1 Computer requirements
The Device Manager server and XP Provisioning Manager server can be used in the following OS
environments:
• Windows
• Linux
The following sections describe the computer requirements for each OS. For details about the
installation, see the HP StorageWorks XP Command View Advanced Edition software installation
guide for Device Manager, Provisioning Manager and Tiered Storage Manager.
1-3-1-1 Requirements when using Windows as the management server OS
The following table shows the OSs that can be used on a management server in a Windows
environment.
Table 1-2 Usable management server OSs (Windows)
OS Edition Service pack Cluster
environment
support
IPv6
environment
support
Windows Server
2003
(x86)
Datacenter Edition
Enterprise Edition
Standard Edition
SP2 Y Y
