Settings for CIM/WBEM (SMI-S CIMOM)
123
Table 7-4 Values you need to specify in the perf_cmddev.properties file
Setting item Value
RAID-ID
Specify one of the following depending on the type of the target
storage subsystem:
R600 for HP XP24000
R601 for HP XP20000
R500 for HP XP12000
R501 for HP XP10000
R502 for SVS200
Serial-number
Specify the serial number of the storage subsystem by using a
decimal (base 10) number.
SLPR-number
Specify the number of the SLPR to which the command device
belongs by using a decimal (base 10) number. If no SLPR is
configured, specify 0.
This item is optional. If you omit this item or define this item by
using the format for version 6.3 or earlier, it is assumed that no
SLPR has been configured.
LDEV-number
Specify the CU:LDEV number of the command device by using a
decimal (base 10) number.
deviceFileName
Specify the command device identifier (the PhysicalDrive number,
VolumeGUID, or device file name) that the host recognizes in the
following format:
*
• In Windows:
\\.\PhysicalDriveX
\\.\Volume{GUID}
• In Linux:
/dev/sdX
X is an integer.
•
*:
If this item is specified using the physical drive number in Windows or Linux and you then restart the OS,
the physical drive number and device file name might be changed. If this occurs, you need to execute the
perf_findcmddev command to check and update the settings. In Windows, if you specify this item using
the volume GUID, the setting is not affected even if you restart the OS.
• If you are using the Device Manager agent version 6.3 or earlier and you want to acquire performance
information of all SLPRs in an SLPR environment, you need to define SLPR0 command device in the
perf_cmddev.properties file.
To define command devices for different SLPRs that belong to the same storage subsystem, define the
SLPR0 command device in the first line of the storage subsystem. The following example shows how to
define PhysicalDrive5 (whose LDEV number is 345) as the SLPR0 command device of
XP12000/XP10000/SVS200 (whose serial number is 14050).
R600.44332.456: \\.\PhysicalDrive3
R500.14050.345: \\.\PhysicalDrive5
R500.14050.346: \\.\PhysicalDrive6
R500.14050.347: \\.\PhysicalDrive10
R501.89832.780: \\.\PhysicalDrive15
7-7-2-5 Format of the perf_findcmddev command
The perf_findcmddev command allows you to set the command device in the
perf_cmddev.properties file.
To execute this command, you must have Administrator permissions (for Windows) or root
permissions (for Linux).
The format of the perf_findcmddev command is as follows:
