Obtain these values from the execution result of the GetStorageArray command. In the execution
result, use the arrayType value or the displayArrayType value to specify the model para-
meter, and use the serialNumber value to specify the serialnum parameter.
Command execution example
hdvmcli DeleteArrayReservation -o "D:\logs\DeleteArrayReservation.log"
"model=XP12000" "serialnum=14009"
Command execution result
RESPONSE:
(Command completed; empty list returned)
DeleteExternalArrayGroup
DeleteExternalArrayGroup deletes mapping of the volume (external volume) of an externally
connected storage system (external storage system) that is mapped on a one-to-one basis to an internal
volume, and deletes the parity group (external parity group). This command also deletes the LU that
belongs to the deleted external parity group.
NOTE:
• This command can be used only with P9500 and XP24000/XP20000. The microcode version
required for XP24000/XP20000 is 60-06-00-XX/XX or later.
• Before you can execute this command, both the storage system in which to create an external
parity group and the externally connected storage system must be registered as Device Manager
management targets.
Parameters
Table 32 DeleteExternalArrayGroup command parameters
DescriptionStatusParameter name
Serial number of the storage system where you want to delete the
external parity group
Required
serialnum
Model of the storage system where you want to delete the external
parity group
Required
model
List of external parity group names to be deleted
Use a comma to delimit multiple values.
Required
arraygroup-
names
Parameter values to obtain in advance
serialnum and model
