DescriptionAttribute
Name of VolumeConnection
This item is output if it has been registered.
name
storage system type to which an external volume is mapped
• P9500: P9500
• XP24000: XP24000
• XP20000: XP20000
• XP12000: XP12000
• XP10000: XP10000/SVS200
mappedArrayType
Serial number of the storage system to which an external volume is mapped
mappedSerialNumber
Device number of the internal volume to which an external volume is mapped
mappedDevNum
storage system type consisting of external volumes
externalArrayType
Serial number of the storage system consisting of external volumes
Unknown is output if the serial number is unknown.
externalSerialNum-
ber
Device number of the external volume
externalDevNum
Volume name of the external volume
externalVolumeName
Product name of the external volume
The product name might not be the same as the product name of the storage
system.
productName
Vendor name of the external volume
vendor
Display name of the device number of the internal volume to which the external
volume is mapped
For P9500 or XP24000/XP20000:
The value is output in the ww:xx:yy format, where ww is the logical DKC
number, xx is the CU number, and yy is the LDEV number.
For XP12000/XP10000/SVS200 or XP1024/XP128:
The value is output in the xx:yy format, where xx is the CU number and yy
is the LDEV number.
displayMappedDevNum
Display name of the external volume device number
The output format is the same as displayMappedDevNum.
displayExtern-
alDevNum
WWN instance
The WWN instance is output when the following commands are executed:
• AddLun, page 233
• AddWWNForHostStorageDomain, page 238
• GetHost, page 256
• GetStorageArray (subtarget=HostStorageDomain) , page 141
• GetStorageArray (subtarget=LogicalUnit) , page 150
