DescriptionAttribute
Type of the drive
• 1: SATA
• 4: SAS
• 5: SSD
• -1: If any of the following conditions are satisfied
• The drive type is unknown
• Drive types are mixed
• Drives with different drive speeds are mixed
diskType
Indicates whether the volumes that make up the hardware tier are internal or
external volumes:
• 0: Internal volume
• 1: External volume
• -1: Unknown, or internal volumes and external volumes are mixed
substance
Port instance
The Port instance is output when the following commands are executed:
• GetStorageArray (subtarget=Port) , page 172
• ModifyPort, page 201
Table 141 Port instance attributes
DescriptionAttribute
Object ID of the port
objectID
Port name
This item is output if it has been registered.
name
Port ID
portID
Port type (example: Fibre)portType
Address of the Fibre port (AL_PA)
For P9500, XP24000/XP20000, XP12000/XP10000/SVS200, or
XP1024/XP128, either of the following values is output:
• 00 or no value: Neither a Fibre port nor an FCoE port
• 01 - EF: Valid address (two-digit hexadecimal number)
fibreAddress
Fibre topology
topology
Display name of the port
displayName
Indicates whether LUN security is valid for the port.
• true: Valid
• false: Not valid
lunSecurityEnabled
Port controller ID
controllerID
