DescriptionAttribute
Usage of on the THP/Smart volume (KB)
One of the following values is output for P9500 or XP24000/XP20000:
• When the logical unit does not consist of THP/Smart volumes: The same value
as capacityInKB.
• When the logical unit consists of THP/Smart volumes: Usage of on the
THP/Smart volumes.
-1 is output for other storage systems.
For P9500 or XP24000/XP20000, note the following points on the value that is
output for THP/Smart volume usage:
• When the THP/Smart volumes are not assigned to a THP/Smart pool, 0 is
displayed.
• When the operator is a partitioned storage manager, -1 is output.
• Volume capacity is allocated from the logical unit in units of tens of megabytes,
so, when the usage rate of the logical unit reaches 100%, the value of con-
sumedCapacityInKB might not match the value of capacityInKB.
• This value might increase significantly depending on the combination of the
file system and the OS of the host that is using the THP/Smart volumes. For
details, see the Thin Provisioning documentation.
consumedCapa-
cityInKB
Pool ID of the Thin Provisioning
One of the following values is output for P9500 or XP24000/XP20000:
• When the logical unit consists of THP/Smart volumes: Pool ID of the THP/Smart
pool to which the THP/Smart volumes are assigned.
#1, #2
• When the logical unit consists of THP/Smart pool volumes: Pool ID of the
THP/Smart pool that contains the THP/Smart pool volumes.
#2
• For other volumes : -1 is output.
#1
When the THP/Smart volumes are not assigned to a THP/Smart pool, -1 is
displayed.
#2
When the operator is a partitioned storage administrator, -1 is displayed.
-1 is output for other storage systems.
thpPoolID
Usage rate threshold of the THP/Smart volumes
One of the following values is output for P9500 or XP24000/XP20000:
• When the logical unit consists of THP/Smart volumes: usage rate threshold
value of the THP/Smart volumes
#1, #2
#1 When the THP/Smart volumes are not assigned to a THP/Smart pool, -1
is displayed.
#2 When the operator is a partitioned storage administrator, -1 is displayed.
• For volumes other than THP/Smart volumes : -1 is output.
-1 is output for other storage systems.
threshold
Currently, this information does not apply to storage systems (-1 is output).tcaPoolID
The name of the parity group to which the logical unit belongs
arrayGroupName
Output items346
