DescriptionAttribute
Usage rate threshold of the THP/Smart volumes.
One of the following values is output for P9500 or XP24000/XP20000:
• When the logical unit consists of THP/Smart volumes: usage rate threshold
value of the THP/Smart volumes
#1, #2
• For volumes other than THP/Smart volumes : -1 is output.
#1
When the THP/Smart volumes are not assigned to a THP/Smart pool, -1 is
displayed.
#2
When the operator is a partitioned storage administrator, -1 is displayed.
-1 is output for other storage systems.
threshold
Indicates whether the LDEV is being used as a system drive.
One of the following values is output for P9500 or XP24000/XP20000:
• -1: Unknown
• 0: Not being used as a system drive
• 1: Being used as a system drive
0 is output for other storage systems.
systemDisk
Name of the parity group to which the LDEV belongs
GroupName
Indicates whether the data that is stored in the LDEV is encrypted.
One of the following values is output for P9500, XP24000/XP20000, or
XP12000/XP10000/SVS200:
• 0: The data is not encrypted.
• 1: The data is encrypted.
-1 is output for other storage systems.
encrypted
Capacity (KB) that has been assigned to THP/Smart volumes from the hardware
tier whose ID (tierID) is 0
thpTier0ConsumedCa-
pacityInKB
Capacity (KB) that has been assigned to THP/Smart volumes from the hardware
tier whose ID (tierID) is 1
thpTier1ConsumedCa-
pacityInKB
Capacity (KB) that has been assigned to THP/Smart volumes from the hardware
tier whose ID (tierID) is 2
thpTier2ConsumedCa-
pacityInKB
Tiering policy applied for Smart volumes
This attribute is valid only when Smart volumes are used in P9500.
For details about the output values, see the tieringpolicy parameter in Table
75.
tieringPolicy
Indicates whether a Smart volume is subject to hardware tier relocation.
This attribute is valid only when a Smart volume is used in P9500.
• enable: Subject to hardware tier relocation
• disable: Not subject to hardware tier relocation
tierRelocation
External LDEV tier rank
This attribute is output only if the microcode version of P9500 is 70-04-00-00/00
or later and the THP/Smart pool volume is an external volume.
externalTierRank
