HP P9000 Command View Advanced Edition Suite Software 7.4.0-00 CLI Reference Guide (TB581-96326, December 2012)

Parameters
Table 112 ModifyReplication command parameters
DescriptionStatusParameter name
Number of the copy groupRequired
replication-
groupid
Specify one of the following values:
• split: Split the copy pair.
• resync: Re-synchronize the copy pair from the primary
volume (P-VOL) to the secondary volume (S-VOL).
• restore: Re-synchronize the copy pair from the S-VOL to the
P-VOL.
If you re-synchronize a Snapshot copy pair, the copy pair is split
after the re-synchronization. For this reason, the paired volume
status is set to PAIR, and then changes toPSUS.
Required
operation
Serial number of the storage system that contains the P-VOLOptional
pvolserialnum
#
Device number of the P-VOL
For P9500 and XP24000/XP20000:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format ww:xx:yy, where
ww is the LDKC number, xx is the CU number, and yy is the
LDEV number. ww is optional. If ww is omitted, LDKC is as-
sumed to be 0.
For XP12000/XP10000/SVS200 and XP1024/XP128:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format xx:yy, where xx is
the CU number, and yy is the LDEV number.
The execution results are output in decimal.
Optional
pvoldevnum
#
Serial number of the storage system that contains the S-VOL
If you specify this parameter, specify either svolserialnum or
svolsequencenum. Do not specify both parameters at the same
time. If they are specified at the same time, an error will occur.
Optional
svolserialnum
#
Sequence number of the storage system that contains the S-VOL
If you specify this parameter, specify either svolserialnum or
svolsequencenum. Do not specify both parameters at the same
time. If they are specified at the same time, an error will occur.
Optional
svolsequen-
cenum
#
Command reference318
