Command execution example 2
This example obtains the controller pair information in all storage systems that have been registered
in the Device Manager database.
hdvmcli GetReplicationControllerPair
-o "D:\logs\GetReplicationControllerPair.log"
Command execution result 2
RESPONSE
An instance of ReplicationControllerPair
objectID=*****
masterArrayType=XP12000
masterSerialNumber=14053
masterControllerID=0
masterStartDevNum=0
displayMasterStartDevNum=00:00
masterEndDevNum=16,383
displayMasterEndDevNum=3F:FF
remoteArrayFamily=XP12K/10K/SVS200
remoteArrayType=Unknown
remoteSerialNumber=14050
remoteSSID=0
remoteControllerID=0
remotePathGroupID=165
remoteStartDevNum=-1
remoteEndDevNum=-1
pairType=0
bandwidth=-1
numOfMinConnection=1
.
. (repeated for other ReplicationControllerPair instances)
.
*****: The value is encoded by the CLI.
ModifyReplication
The ModifyReplication command is used to change the status of a copy pair.
NOTE:
You cannot perform any operations for Fast Snap.
CLI Reference Guide 317
