HP P9000 Command View Advanced Edition Suite Software 7.4.0-00 CLI Reference Guide (TB581-96326, December 2012)

DescriptionStatusParameter name
Device number used to identify the new path (not provided when
a LUSE is defined)
For P9500 and XP24000/XP20000:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format ww:xx:yy, where
ww is the LDKC number, xx is the CU number, and yy is the
LDEV number. ww is optional. If ww is omitted, LDKC is as-
sumed to be 0.
For XP12000/XP10000/SVS200 and XP1024/XP128:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format xx:yy, where xx is
the CU number, and yy is the LDEV number.
The execution results are output in decimal.
Specify either devnum or lusedevnums. Do not specify both
parameters at the same time. If they are specified at the same
time, an error will occur.
Optional
devnum
Comma-separated list of LDEV device numbers to create a LUSE
for the path
For P9500 and XP24000/XP20000:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format ww:xx:yy, where
ww is the LDKC number, xx is the CU number, and yy is the
LDEV number. ww is optional. If ww is omitted, LDKC is as-
sumed to be 0.
For XP12000/XP10000/SVS200 and XP1024/XP128:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format xx:yy, where xx is
the CU number, and yy is the LDEV number.
Use a comma to delimit multiple values.
The execution results are output in decimal.
Specify either devnum or lusedevnums. Do not specify both
parameters at the same time. If they are specified at the same
time, an error will occur.
Optional
lusedevnums
#
#
The LUSE is created using the LDEVs of the specified device numbers. The new LUSE is created
using only those LDEVs that have the same emulation, sizeInKB, and raidType attributes.
Parameter values to obtain in advance
serialnum and model
Obtain these values from the execution result of the GetStorageArray command. In the execution
result, use the arrayType value or the displayArrayType value to specify the model para-
meter, and use the serialNumber value to specify the serialnum parameter.
port, domain, domainnickname, and lun
Obtain these values from the execution result of the GetStorageArray (subtarget=Host-
StorageDomain, hsdsubinfo=freelun) command. Execute this command by specifying
only the model and serialnum parameters, HostStorageDomain for the subtarget
parameter, and freelun for the hsdsubinfo parameter. In the execution result of this command,
the portID, domainID and nickname values appear under An instance of HostStor-
CLI Reference Guide 235
